Catellani&Smith: Jackie O

Jackie O



img-jackie-o-off
The light

The origins

Jackie O was developed at the request of an architect, who wanted to place the “Wa Wa” light over a large table. While working on the project, Enzo Catellani realised the unique quality of the item he had in his hands. He strived once again to achieve “absolute zero” and hoped even to eliminate the cable, which he did so by developing, for the very first time, an extremely thin cable covered in blue fabric, later also used in other items.

The basic rule that I’ve set for everything I do and that I’ve instilled in my collaborators is to put your heart and soul into what you’re doing.

Enzo Catellani

The making of

The time it takes to make a well-made lamp, is the time it takes to make a lamp well-made.

Enzo Catellani


More details

img-dettaglio-jackie-o
Click and explore Drag and explore
Close

Available versions

  • nickel

Datasheet

Materials and colours

blue cable, nickel-plated copper curl, removable glass lens, nickel ceiling jack connection (mod. JC) or nickel recessed plate with tensioner (mod. IC)

Light source

interchangeable LED 1x1W / rated output 1W 350mA / energy class A+ / lumen 100 / K 2700 / CRI 80

Power supply

driver not included
power supply kit available on request

Dimensions

mod. JC
H 120 cm not adjustable,
lens Ø 32 mm,
hole for jack Ø 1,3 cm,
min depth 3,5 cm

mod. IC
H 175 cm adjustable,
plate Ø 7 cm,
lens Ø 32 mm,
hole Ø 5,5 cm,
min depth 3,5 cm

Order code

JOJCmod. JC
JOICmod. IC

Power Supply Unit

K0WS6W driver kit / not dimmable / max 5x1W lamps
K1WS6W driver kit / 1...10V-PUSH dimmable / max 5x1W lamps
K6WS40W driver kit / 1...10V-PUSH-DALI dimmable / max 21x1W lamps
K7WS24,5W driver kit / Triac/IGBT dimmable / max 20x1W lamps
