Jackie O

Jackie O

BIM


img-jackie-o-off
Switch on The light

The origins

Jackie O was developed at the request of an architect, who wanted to place the “Wa Wa” light over a large table. While working on the project, Enzo Catellani realised the unique quality of the item he had in his hands. He strived once again to achieve “absolute zero” and hoped even to eliminate the cable, which he did so by developing, for the very first time, an extremely thin cable covered in blue fabric, later also used in other items.

It is not difficult to find something in this world that can be manufactured slightly worse and sold at a lower cost. The true victim of this situation is he who considers only the price.

John Ruskin

The making of

My past and what I built so far are part of me, but Enzo Catellani was born today, with the desire to travelling backwards to rediscover the primal instinct of doing, for the pleasure of creating.

Enzo Catellani


More details

img-dettaglio-jackie-o
Close
Click and explore Drag and explore

Available versions

  • nickel

Datasheet

Type

pendant lamp

Materials and colours

blue wire, nickel-plated copper curl, removable glass lens, nickel ceiling jack connection (mod. JC) or nickel recessed plate with tensioner (mod. IC)

Light source

interchangeable LED 1x1W / rated output 1W @350mA / energy class A+ / lumen 100 / K 2700 / CRI 80

Power supply

driver not included - power supply kit available on request

Dimensions

mod. JC
H 120 cm not adjustable,
lens Ø 32 mm,
hole for jack Ø 1,25 cm,
min. depth 3,5 cm

mod. IC
H 175 cm adjustable,
plate Ø 7 cm,
lens Ø 32 mm,
hole Ø 5,5 cm,
min. depth 3,5 cm

Order code

JOJCmod. JC / with jack
JOICmod. IC / with plate

Power Supply Unit (available on request)

K0WS6W driver kit / not dimmable / max 5x1W lamps
K1WS6W driver kit / 1...10V-PUSH dimmable / max 5x1W lamps
K6WS39W driver kit / 1...10V-PUSH-DALI dimmable / max 21x1W lamps
K7WS24,5W driver kit / Triac/IGBT dimmable / min.15/max 20x1W lamps
